Especially suitable for the transfer of gasoline, kerosene, AVGAS, JET A-1, diesel (ask for other liquids)

• Diesel & Petrol Filtration: 5 µm (micron)
• Biodiesel Filtration: 25 µm (micron)
• Water decanter: by water repellent filtering paper, with water decanting of 93 % (FG-100 & FG-100G)
• Capacity: 2 litres
• Transfer capacity: 105 l/min
• Upper microfilter housing: aluminium
• Housing: transparent
• Inlet / Outlet: F1" BSP flanges or threads
• Filtering capacity: 500.000 litres (normal conditions)
• Installation: On the pumping kit suction or delivery
• Max. working pressure: 5 bar
• Drain valve



IT IS SUPPLIED WITH

Housing (vessel) + filtering cartridge + Key for a QUICK replacing of the filtering cartridge, unscrewing its ring.

Dimensions & Weight

• Box Dim.: 190x230x330 mm (length x width x height)
• Box gross weight: 1.92 kg

OPTIONAL:

Cartridge replacing key - Part No. 660705000
5 µm (micron) paper filtering element spare kit + joints - Part No. 660708001
F1'' aluminium fixation flange - Part No. 800003032
